TRICONEX 3700A TMR AI Module – Efficient Investment Solution
The TRICONEX 3700A AI Analog Input Module provides reliable analog signal processing with a focus on cost efficiency. It’s designed to work seamlessly in industrial automation systems, offering high accuracy and robust performance at a reduced investment cost.
Model Type:Analog I/O Module
Model Number:3700A
Manufacturer:Triconex
Voltage:0-5V, + 6%
Type:TMR, AI
Number of Input Points:32, diff, DC coupled
Isolated Points:No
Input Update Rate:55 ms
Resolution:12 bits
Accuracy:< .15% of FSR, from 0° to 60°C
Input Resistance (load):30 MΩ (DC), min.
Power-Off Resistance:30 KΩ (DC), typical
Common Mode Rejection:-80 dB (DC-100Hz), typical
Common Mode Range:-12V to +12V peak
Leg-to-Leg Isolation:200 KΩ, typical
Normal Mode Rejection @ 8Hz:-3 dB
Normal Mode Rejection @ 60Hz:-17 dB
Normal Mode Rejection @ 120Hz:-23 dB
The TRICONEX 3700 Digital Input Module is a robust solution designed specifically for industrial environments. Its core functionality includes monitoring digital inputs from various sources, providing reliable feedback to control systems. With 16 input channels, this module can handle a wide range of signals, including dry contact, TTL, and transistor types, making it highly versatile for different applications. Built with industrial-grade components, it operates efficiently over a broad temperature range from -40°C to +85°C, ensuring consistent performance under harsh conditions. This module comes with multiple certifications, including CE, UL, FM, ATEX, and IECEx, guaranteeing compliance with international safety standards. Additionally, the TRICONEX 3700 module is designed with advanced diagnostic capabilities, allowing for real-time monitoring and troubleshooting, reducing maintenance time and improving system uptime. Its seamless integration with TRICONEX controllers ensures a smooth setup process, minimizing configuration complexity. Invest in reliability and efficiency with the TRICONEX 3700 Digital Input Module.
