Schneider NSX160H Circuit Breaker Maintenance & Operation
This comprehensive guide provides detailed instructions for operating and maintaining Schneider‘s NSX160H circuit breaker, ensuring optimal performance and longevity. It covers essential aspects including installation, troubleshooting, and maintenance procedures.
Manufacturer:Schneider
Product Model:NSX160H
Type:Circuit Breaker
Rated Current:160A
Rated Voltage:440V
Ingress Protection Rating:IP20
Operating Temperature Range:-5°C to 40°C
Number of Poles:3P/4P
Breaking Capacity:65kA at 440V AC
The Schneider NSX160H Circuit Breaker offers robust and reliable performance in demanding industrial settings. Its microprocessor-based technology ensures accurate detection of overcurrents and short circuits, thereby safeguarding equipment and personnel. This model comes with a compact design, making it ideal for space-constrained environments. The breaker is easy to install and maintain, featuring a user-friendly interface for operational parameters setting. With a breaking capacity of 50kA at 400V, this circuit breaker is capable of handling significant electrical loads efficiently. The device is constructed with durable materials to withstand harsh conditions, ensuring longevity and consistent operation. Additionally, its thermal and magnetic protection mechanisms provide comprehensive safety, making it an essential component in any industrial control system.
