Rockwell Automation 845H-SJJB24DRYR5 Size 25 Incremental Encoder

Rockwell Automation 845H-SJJB24DRYR5 Size 25 Incremental Encoder

    The A-B 845H-SJJB24DRYR5Size 25 Incremental Encoder is a high-performance encoder designed for industrial automation systems. It is suitable for use in machinery control systems where precise position feedback is required.

Manufacturer:Rockwell Automation

Model:845H-SJJB24DRYR5Size 25

Type:Incremental Encoder

Resolution:25 lines per revolution

Operating Voltage:24V DC

Current Rating:200mA

Output Signal:Push-pull

Shaft Diameter:8mm

Shaft Material:Steel

Environmental Protection Rating:IP65

Weight:0.2kg

Dimensions:50mm x 30mm x 20mm

    The A-B 845H-SJJB24DRYR5Size 25 Incremental Encoder is built for durability and reliability in harsh industrial environments. Its robust design includes an IP65 protection rating, ensuring that it can withstand dust, water, and other contaminants. With a resolution of 2500 PPR, this encoder provides precise feedback on the position and movement of machinery, critical for accurate process control.

    This encoder utilizes a sinusoidal output signal, which delivers smooth and accurate position data even at high speeds. The unit‘s compact size and lightweight design make it easy to integrate into existing systems without requiring significant space or weight considerations.

    Installation is straightforward, with the encoder featuring a 10mm shaft diameter and 30mm length, compatible with standard mounting interfaces commonly found in industrial equipment. The operating temperature range from -20°C to +85°C ensures reliable performance in a wide variety of environmental conditions, making it suitable for both indoor and outdoor applications.

    Enhance your industrial control systems with the precision and reliability offered by the A-B 845H-SJJB24DRYR5Size 25 Incremental Encoder. This encoder is an essential component for any application demanding high accuracy and robustness.
