Rockwell Automation 1769-OF8CK CompactLogix 8 Channel Analog Output Module

Rockwell Automation 1769-OF8CK CompactLogix 8 Channel Analog Output Module

    The Rockwell Automation 1769-OF8CK CompactLogix 8 Point Analog Output Module is designed for precise control applications in industrial automation. This module offers eight channels of analog output, capable of driving current signals to various actuators and control devices. It is ideal for applications requiring accurate current manipulation in manufacturing processes.

Model:1769-OF8CK

Manufacturer:Rockwell Automation

Type:CompactLogix Analog Output Module

Number of Channels:8

Output Type:Analog Current Output

Output Range:0-20 mA

Voltage Range:18-30 VDC

Current Consumption:N/A

Operating Temperature:-25°C to +60°C

Storage Temperature:-40°C to +85°C

Dimensions:1.02″ H x 3.58″ W x 4.72″ L

Weight:0.2 lbs

    The Rockwell Automation 1769-OF8CK CompactLogix 8-Point Analog Output Module is a high-performance component designed for use in a variety of industrial automation settings. It provides reliable analog output control with precision and accuracy.

    This module supports 8 points of analog output, each capable of delivering a current range of 0-20mA. It’s suitable for applications that require precise control over process variables such as flow rate or temperature.

    With its robust design, the module offers overvoltage and short-circuit protection, ensuring safe operation even under challenging conditions. The compact size allows it to be easily integrated into existing systems without taking up excessive space.

    Installation is straightforward, thanks to clear labeling and wiring diagrams provided with the module. It can be mounted directly on DIN rails or panel-mounted, providing flexible installation options.

    For maintenance and troubleshooting, the module features diagnostic LEDs that indicate operational status. This makes it easier to monitor performance and quickly identify any issues.
