NI SCXI-1520 High-Performance Analog Input Module

NI SCXI-1520 High-Performance Analog Input Module

    The National Instruments SCXI-1520 Analog Input Module provides high-speed analog signal acquisition for industrial control systems, offering precision and reliability in various measurement applications.

Brand:NI

Model:SCXI-1520

Output Frequency:Up to 1 MHz

Input Range:+/-10V

Resolution:16 bits

Accuracy:+/-0.025% of reading + 10uV

Number of Channels:8

Connector Type:Screw Terminal

Power Supply:External DC power supply

Operating Temperature Range:-40°C to +85°C

Certifications:CE, RoHS

    The NI SCXI-1520 is an essential component in industrial control systems. Designed for precision and reliability, it offers 8 channels of analog input capable of measuring voltages from +/-10V with 16-bit resolution. This ensures accurate and consistent data acquisition across various applications.

    With a sampling rate of 100 kS/s, the SCXI-1520 can capture fast-changing signals without loss of detail, making it ideal for real-time process control and monitoring. Its robust design includes overvoltage protection up to ±30V, ensuring reliable operation even under harsh conditions.

    The module is easy to integrate into existing systems thanks to its standard connector types and compatibility with NI’s SCXI chassis. Its compact form factor allows for efficient use of space in control panels and enclosures.

    Designed for durability, the SCXI-1520 uses high-quality components and materials to withstand the rigors of industrial environments. Its CE, UL, and CSA certifications guarantee compliance with international safety standards.

    For system integrators and engineers looking to enhance their data acquisition capabilities, the NI SCXI-1520 is a reliable choice. With its precise measurements and robust design, it is well-suited for applications in manufacturing, research, and process control.
