NI PXIE-7966R High-Performance FPGA Module for Industrial Automation

NI PXIE-7966R High-Performance FPGA Module for Industrial Automation

    The NI PXIe-7966R is a high-performance FPGA module designed for industrial automation systems. It offers unparalleled flexibility and speed for data acquisition and control applications. Ideal for real-time processing and complex system integration.

Manufacturer:National Instruments

Model Number:PXIE-7966R

Series:CompactRIO

Form Factor:PCIe x4

FPGA Type:Altera Cyclone V

RAM:1 GB DDR3L

Clock Speed:500 MHz

Digital I/O Channels:256

Analog I/O Channels:16

Power Supply Requirements:12V DC, 10W

Operating Temperature Range:-40°C to +85°C

Certifications:CE, RoHS, UL

    The NI PXIe-7966R is a cutting-edge FPGA module ideal for engineers looking to design custom high-speed test systems or implement complex control algorithms in industrial environments. With its robust Xilinx Kintex UltraScale KU060 FPGA, this module delivers unparalleled performance for real-time signal processing and data acquisition. The module’s extensive I/O capability, including up to 8 analog input and output channels, allows for versatile application across various industries, from automotive and aerospace to semiconductor manufacturing.

    Designed for durability and reliability, the PXIe-7966R operates within a wide temperature range (-40°C to +85°C), making it suitable for harsh industrial settings. Its compact size (3.5 x 5.5 x 1.5 inches) ensures easy integration into existing PXI systems without compromising on performance.

    Key Features:

    – Xilinx Kintex UltraScale KU060 FPGA for advanced signal processing

    – Up to 8 analog input/output channels for flexible configuration

    – Operates within -40°C to +85°C for reliable performance in extreme conditions

    – Compact form factor for seamless integration into PXI systems

    Installation and Use:

    The module can be easily installed in any compatible PXI chassis. For optimal use, refer to the user manual for detailed instructions on connecting the module to your system and configuring the FPGA to suit your specific application needs.
