NI PCIe-6548 Data Acquisition Module – High-Speed Digital I/O

NI PCIe-6548 Data Acquisition Module – High-Speed Digital I/O

    The NI PCIe-6548 is a high-density digital input/output module designed for high-performance test and measurement applications in industrial control systems. It offers 48 differential digital I/O channels with fast data acquisition and transmission capabilities.

Manufacturer:National Instruments

Model:PCIe-6548

Submodel:781012-03

Interface:PCI Express

Channels:48 Differential Digital I/O Channels

Digital I/O Type:High-Density

Data Rate:Up to 100 MHz

Power Supply:3.3 V or 5 V

Operating Temperature Range:-40°C to 85°C

Dimensions:126.7 mm x 107.4 mm x 25.4 mm

Weight:Approximately 300 g

    The National Instruments PCIe-6548 Data Acquisition Module is an essential tool for engineers and scientists who require high-quality data acquisition capabilities. This module supports up to 8 analog input channels, offering a sample rate of up to 1 MS/s per channel. With a 16-bit resolution and an input range of +/-10V, it is ideal for a wide range of test and measurement applications.

    Designed for seamless integration, the PCIe-6548 is compatible with Windows, Linux, and macOS operating systems. Its compact form factor ensures easy installation and minimal space requirements, making it perfect for both benchtop and rack-mount setups.

    Key Features:

    – High-speed data acquisition at up to 1 MS/s per channel

    – 16-bit resolution for precise measurements

    – Wide input range of +/-10V

    – Compatible with multiple operating systems

    – Compact design for efficient use of space

    This module comes with robust software support, including NI-DAQmx drivers and LabVIEW software, allowing for straightforward setup and configuration. Whether you are conducting research, developing new products, or maintaining existing systems, the NI PCIe-6548 provides the reliable data acquisition performance you need.
