NI PCI-6040E Data Acquisition Module

NI PCI-6040E Data Acquisition Module

    The NI PCI-6040E is a high-performance data acquisition module designed for industrial automation and control systems. It facilitates precise analog input and output operations, making it ideal for test, measurement, and control applications in various industries.

Manufacturer:National Instruments

Model Number:PCI-6040E

Interface Type:PCI

Digital Channels:32 channels (16 inputs, 16 outputs)

Sampling Rate:Up to 1 MHz per channel

Voltage Range:TTL (0 to 5 V)

Power Supply:5 VDC ±5%

Connector Type:RJ45 connector

Operating Temperature:-40°C to +85°C

    Designed for demanding industrial environments, the NI PCI-6040E offers reliable performance under harsh conditions. Its robust construction ensures long-term stability and durability.

    The module supports up to 8 analog input channels and 2 analog output channels, providing versatile connectivity options for various applications. With a sampling rate of up to 2 MS/s per channel, it excels in capturing rapid changes in data streams.

    Equipped with a 16-bit resolution, the NI PCI-6040E delivers precise measurements, ensuring accurate and reliable data acquisition. Its wide analog input range of +/-10V accommodates a broad spectrum of sensor signals.

    The power supply requirement is 5 VDC, making it easy to integrate into existing systems. It operates efficiently over a wide temperature range from -40 to 85°C, suitable for outdoor or industrial settings.

    Installation is straightforward, thanks to its PCI interface. The compact design allows for easy integration into standard PCI slots, enabling users to quickly set up their data acquisition system without complex wiring.
