NI cFP-TC-125 Thermocouple Module for Compact FieldPoint Systems

NI cFP-TC-125 Thermocouple Module for Compact FieldPoint Systems

    The National Instruments cFP-TC-125 Thermocouple Input Module is designed for precise temperature measurement in industrial environments. This module supports up to 8 thermocouples, offering high accuracy and reliability in various applications including manufacturing, HVAC systems, and process control.

Module Type:Thermocouple Input

Brand:National Instruments

Model:cFP-TC-125

Channel Count:4 channels

Input Range:−200 to 1200°C

Accuracy:±0.1% of reading ±1 least significant bit (LSB)

Supported Thermocouple Types:J, K, T, E, R, S, B, N

Power Requirements:10 to 30 VDC

Operating Temperature:-20°C to 70°C

Dimensions:100mm x 30mm x 25mm

Weight:35g

    The National Instruments cFP-TC-125 is a robust thermocouple input module designed for high-accuracy temperature measurement in industrial environments. With support for up to 4 channels, this module can handle various types of thermocouples including J, K, T, E, R, S, B, and N. Its accuracy is rated at ±0.1% of reading plus 1 least significant bit, ensuring reliable performance across a wide range of temperatures from −200°C to 1200°C. The module operates within a temperature range of -20°C to 70°C, making it suitable for diverse industrial settings. Designed with ease-of-use in mind, the cFP-TC-125 features compact dimensions (100mm x 30mm x 25mm) and a lightweight build (35g), facilitating integration into existing systems without compromising space or weight constraints. It is powered by a stable 10 to 30 VDC supply, ensuring consistent operation under varying conditions. The module also includes built-in protection mechanisms to safeguard against common industrial hazards, providing users with peace of mind and long-term reliability.
