NI BNC-2121 High-Frequency Signal Conditioning Module

NI BNC-2121 High-Frequency Signal Conditioning Module

    The NI BNC-2121 High-Speed Digital Input Module is designed for industrial applications requiring precise digital signal acquisition. This module offers reliable performance in data acquisition systems, enabling users to capture high-speed signals efficiently.

Brand:National Instruments

Model:BNC-2121

Connector Type:BNC

Impedance:50 Ohms

Frequency Range:DC to 4 GHz

Voltage Rating:300 V

Contact Plating:Gold

Insertion Loss:< 0.2 dB @ 4 GHz

Return Loss:> 20 dB @ 4 GHz

Operating Temperature:-40°C to +85°C

Material:PBT with PTFE insulator

Size:1/4 inch (6.35 mm)

    The NI BNC-2121 Analog Input Module offers unparalleled accuracy and reliability in signal conditioning and data acquisition. It is specifically engineered for industrial automation environments requiring precise measurements. The module’s dual BNC connectors provide a robust connection for analog signals, ensuring a stable and reliable signal path. With a resolution of 16 bits and a sampling rate of up to 1 MS/s per channel, it delivers high-fidelity data suitable for demanding applications. Its isolation capability of 300Vrms ensures safe operation in electrically noisy environments. Designed for easy integration with other industrial control systems, the NI BNC-2121 can be seamlessly connected to a wide range of sensors and devices. Its compact size and efficient power requirements make it an ideal choice for space-constrained applications.
