National Instruments PXIe-4162 Precision Arbitrary Waveform Generator

National Instruments PXIe-4162 Precision Arbitrary Waveform Generator

    The NI PXIe-4162 is a high-performance arbitrary waveform generator designed for test and measurement applications requiring precise signal generation. It enables researchers and engineers to generate complex waveforms at frequencies up to 65 MHz with excellent fidelity, making it ideal for applications in RF testing, communications, and more.

Sample Rate:Up to 1 GS/s

Output Channels:2

Voltage Range:+/-1 V

Resolution:16 bits

Bandwidth:DC to 400 MHz (-3 dB)

Connectivity:PXI Express, USB 3.0, LAN

Software Support:LabVIEW, SignalExpress

Form Factor:PXIe Module

    The National Instruments PXIe-4162 Arbitrary Waveform Generator delivers unparalleled performance in generating precise waveforms. Its broad frequency range from 9 µHz to 100 MS/s makes it suitable for a wide variety of applications, from low-frequency signals to high-speed digital communication testing.

    With a voltage range of +/- 10V and a 16-bit resolution, the PXIe-4162 ensures accuracy and clarity in signal representation, catering to the most demanding applications where precision is critical.

    This module supports up to two channels, allowing for dual-channel synchronization or independent operation, which is particularly beneficial for applications requiring complex signal interactions or dual-channel data acquisition.

    The PXIe-4162 features a generous memory depth of 64 MSamples, providing ample space for storing waveforms and ensuring seamless operation without the need for constant data reloading. This is especially advantageous in continuous signal generation scenarios.

    Integrated with PXI Express technology, the PXIe-4162 offers fast data transfer rates and robust synchronization capabilities, making it an ideal choice for modern automated test equipment and industrial automation systems.
