National Instruments PXI-2568 High-Speed Digital Multifunction I/O Module
The Advantech PXI-2568 is a high-performance data acquisition module designed for industrial control systems. It enables users to capture, process, and analyze real-time data from various sensors and equipment in a wide range of applications, including manufacturing, automation, and test systems.
Manufacturer:National Instruments
Model:PXI-2568
Module Category:Data Acquisition
Bus Interface:PXI Express
Sampling Rate:25 MS/s per channel
Resolution:16 bits
Channels:2 channels
Analog Input Range:+/-10 V
Digital I/O:32 lines
Power Requirements:10 to 30 VDC
Operating Temperature:-40 to +85°C
Weight:0.25 kg
Dimensions:12.5 cm x 9.5 cm x 3.5 cm
The National Instruments PXI-2568 High-Speed Digital I/O Module is a cutting-edge solution for engineers and researchers looking to enhance their testing and measurement capabilities. This module supports up to 32 channels and operates at sample rates of up to 20 MS/s per channel, making it perfect for high-speed data acquisition tasks. The PXI-2568 boasts a wide voltage range of +5V to +12V, ensuring compatibility with a broad spectrum of devices. Its robust design includes a 26-pin VHDCI connector, which ensures reliable connections even under demanding conditions. With its compliance to PXI/PXI Express standards, this module integrates seamlessly into existing systems, offering seamless upgrades without requiring extensive reconfiguration. Additionally, the PXI-2568 is built to withstand extreme operating temperatures ranging from -40°C to +85°C, making it suitable for a variety of environments. Weighing approximately 0.5kg, it is lightweight yet durable, providing ease of handling during installation and maintenance. This module is indispensable for applications in telecommunications, automotive, aerospace, and semiconductor industries, where precision and reliability are paramount.
