    The DS3800-HPCA-1F1E is a digital pulse controller designed for the Speedtronic Mark IV system. It ensures precise control and monitoring in industrial automation applications, featuring easy installation and reliable performance.

Manufacturer:General Electric

Model Number:DS3800-HPCA-1F1E

Board Type:Digital Pulse Controller

Connector Location:Left Edge

LED Indicators:5 (4 Red, 1 Yellow)

Test Points:9 TP

Switch Component:Yes

Resistors:Metal Film Resistors

Capacitors:Electrolytic and Ceramic Capacitors

Diodes:Yes

Integrated Circuits:34, including an oscillating chip

Dimensions:N/A

Weight:N/A

Compatibility:GE Mark IV Turbine Control Systems

    The DS3800-HPCA-1F1E is a high-quality digital pulse controller manufactured by General Electric. This circuit board is specially designed for the Speedtronic Mark IV system, ensuring optimal performance in industrial automation applications. Featuring a robust design, this controller includes a long right-angled connector, making it easy to connect to other system components. On its right edge, there are nine TP test points and five LED indicators, four of which are red and one yellow, offering clear operational feedback. The board also houses multiple metal film resistors, electrolytic and ceramic capacitors, diodes, and an array of integrated circuits including an oscillating chip for accurate pulse generation. Installation is straightforward with the help of two screws and a pair of clips, allowing for quick and secure attachment. Each part of the DS3800-HPCA-1F1E is meticulously labeled with letters and numbers, making it easy to identify and install correctly. Trust in General Electric’s commitment to quality and innovation by choosing the DS3800-HPCA-1F1E for your critical industrial automation needs.
