GE SR745-W2-P5-G5-HI-A-E Industrial Transformer Protection System
The GE SR745-W2-P5-G5-HI-A-E is an advanced solution designed to manage and protect transformers, autotransformers, and reactors. With its robust features, it ensures optimal operation and longevity of electrical systems.
Windings Per Phase:2
Resistant Temperature Device (RTD) Type:3 wire; 100 Ω Nickel, 120 Ω Nickel, 100 Ω Platinum
Analog Output Maximum Load:10 kΩ at 0 to 1 mA, 600 Ω at 4 to 20 mA
Maximum Continuous Voltage Output:273 V
Display Type:40 character Enhanced LCD
Dimensions:Height 9 inches, Depth 7 ⅛ inches, Width 7 inches
Control Power Range:90 to 300 V DC; 70 to 265 V AC at 48 to 62 Hz
The GE SR745-W2-P5-G5-HI-A-E provides an efficient and reliable solution for transformer protection.
Featuring a user-friendly 40-character enhanced LCD display and an expanded keypad, this model facilitates easy manual entry of setpoints.
With dimensions of 9 inches high, 7 inches wide, and 7 ⅛ inches deep, it is compact enough to mount on a standard 19-inch panel.
The unit comes equipped with LEDs on the front panel that provide real-time alerts for various statuses and errors, ensuring quick response to any issues.
Designed to withstand harsh environments, the system offers a resilient design that helps minimize strain on transformer elements, thus extending the life of your electrical infrastructure.
