GE SR469-P1-HI-A1-E-H Motor Management Relay: Efficient Protection & Control
The SR469-P1-HI-A1-E-H is a high-performance Motor Management Relay by GE Multilin, designed specifically for managing and protecting medium to large motors in industrial settings. It offers a robust solution for motor management, protection, and monitoring.
Manufacturer:General Electric
Model:SR469-P1-HI-A1-E-H
Analog Outputs:0-1 mA
Digital Inputs:9 opto-isolated inputs
Load Shed Timing Accuracy:100 ms max
Manual Reset Timing:1601-0122-AG
Operating Temperature Range:-40°C to +60°C
Storage Temperature Range:-40°C to +80°C
Primary CT Rating:1 to 5000 Amps
Secondary CT Phase:5A
RTD Sensing Current:5 mA
Control Power:90-300VDC and 70-265VAC at 48-62Hz
Voltage Supply:High
Display:Enhanced Display with Larger LCD
Environmental Protection:Harsh Environment Conformal Coating
The GE SR469-P1-HI-A1-E-H Motor Management Relay is meticulously designed for demanding industrial applications. It is equipped with a conformal coating to withstand harsh environmental conditions, ensuring continuous operation even in the most challenging settings. With its enhanced display featuring a larger LCD screen, operators can easily monitor key metrics and system status in real-time.
This motor management relay supports a wide range of motor protection and RTU functions, streamlining overall system management. Its primary current transformer (CT) rating ranges from 1 to 5000 Amps, making it suitable for a variety of industrial motor setups.
Featuring 9 opto-isolated digital inputs and high accuracy load shed timing, this relay ensures precise and reliable operation. The unit is designed to integrate seamlessly into existing systems, serving as either a standalone device or part of a broader control network.
For optimal performance, the SR469-P1-HI-A1-E-H is built to operate within a broad temperature range, from -40°C to +60°C during operation and up to +80°C during storage, making it a versatile solution for various industrial climates.
