GE DS3815PFPA – High Performance Printed Circuit Board

GE DS3815PFPA – High Performance Printed Circuit Board

    The GE DS3815PFPA is a high-performance printed circuit board designed for advanced industrial control systems. It is specifically engineered for use in GE turbine control systems, enhancing system reliability and efficiency.

Module Type:Industrial Control Module

Brand:GE

Model:DS3815

Submodel:PFPA

Technology:High-Speed Digital Signal Processing

Power Requirements:24V DC

Operating Temperature Range:-40°C to +85°C

Mounting Options:Panel Mounting

Dimensions:Width: 100mm x Height: 70mm x Depth: 30mm

Weight:Approximately 500g

    The DS3815PFPA is a printed circuit board manufactured by General Electric, designed for use in GE‘s Mark IV series turbine control systems.

     This board is built with advanced NAND-gates, clock generators, and ready interfaces to support SAB 80286 processors, ensuring robust performance in industrial settings.

     It includes octal D-type latches and dual negative-edge-triggered master-slave J-K flip-flops for enhanced processing capabilities.

     Designed with durability in mind, the DS3815PFPA meets stringent industry standards including CE, UL, and RoHS compliance, making it a reliable choice for any industrial automation setup.

     Installation is straightforward thanks to its intuitive design, allowing for quick integration into existing systems without requiring extensive modifications.
