GE DS3800NSWA1A1B – Printed Circuit Board for Mark IV Speedtronic System

GE DS3800NSWA1A1B – Printed Circuit Board for Mark IV Speedtronic System

    The GE DS3800NSWA1A1B is a high-performance printed circuit board designed for gas/steam turbine systems management within the Mark IV Speedtronic system. It integrates advanced features like quad differential comparators and octal buffers for reliable operation.

Manufacturer:General Electric

Model:DS3800NSWA1A1B

Type:Printed Circuit Board

Circuits:Twelve circuits including quad differential comparators and octal buffers

Optional Auxiliary Board:Yes (DS3800DSWA)

Jumper Switches:Twelve

Potentiometers:Twelve

Voltage Requirements:To Be Confirmed

    Designed as a crucial component for the Mark IV Speedtronic system, the DS3800NSWA1A1B is built with advanced technology to ensure reliable performance in managing gas/steam turbine systems.

    This circuit board incorporates triple-redundancies on all protection parameters and critical controls, which significantly reduces the risk of downtime caused by electronic failures.

    An optional auxiliary daughter board, DS3800DSWA, can be installed to provide access to additional components such as twelve jumper switches and twelve potentiometers, offering enhanced functionality and customization options.

    The DS3800NSWA1A1B is manufactured to the highest quality standards, ensuring durability and long-term reliability in harsh industrial environments.

    Installation is straightforward, and once integrated into the system, the DS3800NSWA1A1B operates seamlessly, providing continuous monitoring and control of turbine systems.
