GE DS3800NMEC1D1B – Printed Circuit Board for Mark IV System
The DS3800NMEC1D1B is a high-quality printed circuit board developed by General Electric (GE) for their Mark IV system. It serves as an integral component in steam and gas turbine management, ensuring efficient operation through automation of critical processes.
Manufacturer:General Electric (GE)
Model Number:DS3800NMEC1D1B
Compatibility:For use with GE Mark IV systems
Board Type:Printed Circuit Board
Dimensions:Approximately 9 inches x 7 inches
Weight:Approximately 1.5 lbs
Power Requirements:Operates within 5V to 24V DC range
Operating Temperature Range:-40°C to +85°C
Storage Temperature Range:-60°C to +100°C
Humidity Range:0% to 95%, non-condensing
Interface Connectors:Five PCB mating connectors including two vertical male pin connectors
Designed by General Electric for the Mark IV series, the DS3800NMEC1D1B board is a critical component in steam and gas turbine systems. Its advanced features include a triple-redundant microcomputer-based control system, which significantly reduces downtime due to electronic failures.
This board is meticulously engineered with quad 2-input NAND buffers and quad voltage comparators, ensuring precise and reliable operation under various conditions. The five PCB mating connectors, including two vertical male pin connectors, facilitate seamless integration with other boards in the system.
The DS3800NMEC1D1B board is built to withstand extreme temperatures, ranging from -40°C to +85°C, making it suitable for harsh industrial environments. It is also rated for 12V DC operation, providing stable power supply for optimal performance.
Maintaining the health of your older Speedtronic systems is now easier than ever with AX Control’s sales and service programs. We provide comprehensive support for discontinued Mark IV components, ensuring your equipment remains operational and efficient.
Upgrade your turbine management system with the DS3800NMEC1D1B board today and experience unparalleled reliability and performance. Trust in General Electric’s expertise and AX Control’s dedication to keeping your systems running smoothly.
