GE 169PLUS-100P-240 Motor Management Relay – Enhanced Power Range Protection

GE 169PLUS-100P-240 Motor Management Relay – Enhanced Power Range Protection

    The General Electric 169PLUS-100P-240 is an advanced Motor Management Relay designed to provide superior control in high-power industrial applications. It offers robust protection and precise monitoring capabilities for motors, ensuring optimal performance and longevity.

Manufacturer:General Electric Multilin

Model Number:169PLUS-100P-240

Relay Dimensions:11.25″H, 7.5″W, 5″H

RTD Input Display Accuracy:±2°C

RTD Inputs:10 Ω copper, 100 Ω nickel, 120 Ω nickel

RTD Trip/Alarm Setpoint Range:0 to 200°C

Differential Relay Response Time:100 msec

Maximum Phase Current Input Range:0.05 to 12 × phase CT primary amps setpoint

Phase Reversal Trip Response Time:within 3.5 sec. of motor start attempt

Power Range:240 VAC, range: 180-270 VAC

    The GE 169PLUS-100P-240 Motor Management Relay is an advanced solution designed for high control power systems, offering exceptional performance and reliability. With its enhanced power range (240 VAC, range: 180-270 VAC), this relay ensures precise and efficient operation under demanding conditions. Its robust RTD inputs support multiple temperature sensing materials, allowing accurate monitoring of motor health. The differential relay response time is impressively fast at just 100 milliseconds, enabling quick reaction to changes in motor performance. Additionally, it features a phase reversal trip response time of under 3.5 seconds upon motor start attempt, safeguarding against potential faults. This model is an ideal choice for industrial applications requiring high standards of motor management and protection.
