B&R X20DC2190 Digital Counting Module, SSI Absolute Encoder Interface
The B&R X20DC2190 Counting Module offers high precision digital counting capabilities tailored for industrial automation environments. It integrates seamlessly into existing systems, enhancing monitoring and control functionalities.
Extended Product Type:SSI Absolute Encoder Counter Module
Product ID:X20DC2190
Nominal Voltage:24 VDC
Input Voltage Range:24 VDC -15% / +20%
Power Consumption (Bus):0.01 W
Power Consumption (Internal I/O):1.1 W
Connection Type:3-wire connections
Status Indicators:I/O function per channel, operating state, module status
The B&R X20DC2190 Digital Counting Module offers precise measurement and control capabilities essential for modern industrial applications. Its advanced design includes support for SSI absolute encoders, allowing it to monitor data signals with 5V precision. With two additional input channels, it can manage power supply requirements for various encoders efficiently.
This module is equipped with indicators that display the status of each I/O function per channel, helping operators quickly identify operational statuses. Designed for robust performance in demanding environments, the X20DC2190 ensures minimal downtime with reliable power consumption levels of 0.01W for bus operations and 1.1W internally.
For integration into existing systems, the X20DC2190 is fully compatible with SafeLOGIC controllers, enhancing its utility in complex automation setups. The module supports a wide voltage range, from 24 VDC -15% to +20%, making it adaptable to diverse power supply conditions.
Installation is straightforward, thanks to its 3-wire connection method, ensuring easy setup without the need for specialized tools. This makes the B&R X20DC2190 a perfect choice for engineers looking to upgrade their control systems with a reliable and versatile component.
With its compact size and durable construction, the B&R X20DC2190 Digital Counting Module stands out as a premium solution for industrial automation. Its combination of precision, flexibility, and ease of use makes it an indispensable asset in any industrial control application.
