B&R X20DC1398 SSI Absolute Encoder Module for Industrial Automation Control

B&R X20DC1398 SSI Absolute Encoder Module for Industrial Automation Control

    The B&R X20DC1398 Digital Counter Module is a high-performance solution designed for precise monitoring and control applications within industrial automation systems. It integrates seamlessly with SafeLOGIC controllers and supports SSI absolute encoders, providing reliable and accurate counting capabilities.

Extended Product Type:Counter Module

Product ID:X20DC1398

Type Designation:Digital Counter Module

Number of Inputs:1 SSI absolute encoder input

Input Voltage Range:5 VDC, 24 VDC

Power Consumption:Bus: 0.01 W, Internal I/O: 1.1 W

Nominal Voltage:24 VDC

Input Voltage Tolerance:-15% / +20%

Connection Type:3-wire connections

    The B&R X20DC1398 Digital Counter Module stands out in the realm of industrial automation for its unparalleled performance and robust design.

     This module is meticulously crafted to deliver top-tier functionality with its compatibility with SSI absolute encoders and dual additional input channels, enabling seamless integration into existing systems.

     The 5VDC, 24VDC, and GND power configurations offer versatility in application scenarios, while the precise monitoring of the data signal ensures minimal error margins.

     Designed with the user in mind, this module includes indicator lights for each channel’s I/O function, operational status, and overall module health, providing real-time feedback for optimal system management.

     With its compact size and efficient energy consumption, the B&R X20DC1398 is engineered to enhance any industrial setting, offering both convenience and excellence.
