B&R 7CM211.7 Digital Input Module for Automation Systems
The B&R 7CM211.7 Digital Input Module is an essential component for industrial automation systems, designed to efficiently process up to 8 digital inputs with 24 VDC. It supports various counter and encoder applications, making it ideal for precise control in manufacturing environments.
Extended Product Type:Digital Input Module
Product ID:7CM2117
Input Channels:8
Input Voltage:24 VDC
Response Time:4 ms
Counter Channels:3 one-channel or 2 two-channel counters
Encoder Support:2 incremental encoders, 20 kHz
Output Channels:8
Output Voltage:24 VDC
Output Current:0.5 A
Comparator Function:Yes
Short Circuit Protection:Yes
Analog Inputs:2, ±10 V / 0 to 20 mA, 12-bit
Analog Outputs:2, ±10 V, 12-bit
This advanced digital input module from B&R integrates seamlessly into industrial automation systems. Its design allows for the precise monitoring of up to 8 digital signals at once, making it a crucial component in manufacturing processes.
With an input voltage range of 24 VDC and a response time of just 4 ms, the module ensures rapid signal detection and response. This is particularly useful in high-speed manufacturing environments where timing is critical.
Equipped with a comparator function and short circuit protection, this module offers robust performance under varying conditions. The ability to support up to 3 one-channel or 2 two-channel counters enhances its versatility across different applications.
The inclusion of 2 analog inputs and outputs with ±10 V and 0 to 20 mA ranges provides flexibility in interfacing with a wide array of sensors and actuators. Its compatibility with 12-bit resolution ensures high accuracy in data acquisition.
Designed for ease of installation and maintenance, this module comes with dedicated terminal blocks (TB718) for secure connections. Its straightforward wiring requirements make it a preferred choice for engineers looking for reliable performance without complex setup.
