Allen-Bradley 2098-DSD-HV050-SE Ultra 3000 5kW SERCOS Servo Drive

Allen-Bradley 2098-DSD-HV050-SE Ultra 3000 5kW SERCOS Servo Drive

    The Allen-Bradley 2098-DSD-HV050-SE is a high-performance SERCOS interface drive designed for complex motion control applications in industrial environments. Featuring robust power output and versatile connectivity options, this drive ensures precise control and efficiency in automation processes.

Input Voltage (AC):230…480V rms, 3-Phase

Nominal Input Current (AC):7 Amps Root Means Square

Continuous Output Current:11 Amps (0-peak)

Intermittent Output Current:22 Amps (0-peak)

Input Frequency (AC):47-63 Hz

Dimensions:9.54 x 14.2 x 5.46 in (242.2 x 360.7 x 138.7 mm)

Bus Overvoltage:810V dc

Shunt On:800V dc

Auxiliary Power Supply:Yes

Communication Interfaces:RS232, RS485 with DeviceNet, SERCOS interface

    The Allen-Bradley 2098-DSD-HV050-SE Ultra 3000 5kW SERCOS Servo Drive is engineered for reliability and efficiency in industrial automation.

     Designed for applications requiring high precision and dynamic response, this drive supports SERCOS, RS232, RS485, and DeviceNet interfaces, providing a comprehensive solution for seamless integration with existing systems.

     Its robust design includes passive shunt resistor connections, a seven-segment fault status indicator, and dedicated slots for RS232 and RS485, enhancing the drive’s functionality and ease of use.

     With a compact form factor, the 2098-DSD-HV050-SE fits easily into tight spaces, making it ideal for a variety of industrial settings.

     Its ability to support multi-turn absolute encoders ensures accurate positioning, critical for manufacturing processes.

     Whether you’re upgrading your existing machinery or building new systems, the 2098-DSD-HV050-SE provides the precision and flexibility needed for today’s demanding industrial environments.
