Allen Bradley 1492-AIFM6TC-3 Thermocouple Input Module for Industrial Automation

Allen Bradley 1492-AIFM6TC-3 Thermocouple Input Module for Industrial Automation

    The Allen Bradley 1492-AIFM6TC-3 Thermocouple Input Module is an essential component designed for industrial automation systems, providing precise temperature measurements through thermocouples. It’s ideal for manufacturing processes requiring high accuracy and reliability.

Module Type:Thermocouple Input Module

Model Number:1492-AIFM6TC-3

Brand:Allen Bradley

Input Channels:6 channels

Temperature Range:-200°C to +1200°C

Accuracy:±0.1% of reading ±1°C

Response Time:Less than 500 ms

Power Supply:24 VDC

Operating Temperature:-40°C to +85°C

Protection Rating:IP65

Mounting Type:Panel Mount

Weight:0.5 kg

    The Allen Bradley 1492-AIFM6TC-3 Thermocouple Input Module is engineered for high-performance temperature sensing in industrial automation systems. Its robust design ensures durability and reliability under harsh conditions. Featuring six channels, this module supports a wide input range of -76.5 to 76.5 mV, with a bandwidth of 0 to 2.62 Hz, making it ideal for precise temperature measurements. The unit is powered by 240V AC and can handle up to three phases with a maximum current of 70A, delivering an impressive power rating of 18.5 HP (25 kW). Designed with safety in mind, the module boasts an IP 20, NEMA/UL Type 1 enclosure rating, protecting against dust and light objects, while its heat sink has an IP66, NEMA/UL Type 4X/12 rating, suitable for both indoor and outdoor use. Additionally, the module includes a blank cover interface for added customization options. With a single red/green power status indicator, monitoring operation is straightforward, ensuring you’re always aware of the module’s operational state.
