A-B 845H-SJDB24CRY2Size 25 Incremental Encoder

A-B 845H-SJDB24CRY2Size 25 Incremental Encoder

    This Rockwell Automation 845H-SJDB24CRY2Size 25 Incremental Encoder is designed for precise position measurement in industrial control systems, providing reliable feedback for motion control applications.

Brand:Rockwell Automation

Model:845H-SJDB24CRY2

Incremental Encoder Type:Incremental Encoder

Size:Size 25

Resolution:2000 PPR (Pulses Per Revolution)

Supply Voltage:5VDC ±10%

Shaft Diameter:10mm

Shaft Material:Stainless Steel

Output Signal:Square Wave TTL

Environmental Protection Rating:IP65

Operating Temperature Range:-20°C to +85°C

Weight:Approx. 200g

    This A-B incremental encoder is built for robust performance in industrial environments. With its high-resolution capability of up to 2500 PPR, it delivers reliable position feedback for a variety of applications. The unit operates efficiently within a wide voltage range of 10-30VDC, making it compatible with a broad array of control systems. Designed with a compact shaft diameter of 6mm and a length of 10mm, this encoder fits seamlessly into tight spaces without compromising on accuracy. The HTL/TTL output signal ensures clear and consistent data transmission, vital for real-time monitoring. Additionally, its IP65 rating guarantees protection against dust and water ingress, extending its operational life under harsh conditions. Ideal for use in manufacturing plants, material handling equipment, and process automation systems, this encoder supports continuous operation in challenging environments.
