A-B 1394C-SJT22-A 8-channel Universal Analog Input Module

A-B 1394C-SJT22-A 8-channel Universal Analog Input Module

    The A-B 1394C-SJT22-A Interface Module is an advanced analog input module capable of high-frequency signal processing. It is specially designed for use in demanding industrial environments, ensuring reliable data acquisition and processing.

Model Number:1394C-SJT22-A

Brand:A-B

Operating Voltage:220 V

Output Frequency:30 kHz

Certified Product:Yes

Series:1394C-SJT22-A

Item Number:1394C-SJT22-A

RTD Short Circuit Detection:Yes

User Defined Range Calibration:Yes

High/High High/Low/Low Low Alarm Detection:Yes

Module Fault Reporting:Yes

Diagnostic Points Support:Yes

Cold Junction Compensation:Yes

Temperature Display:Celsius or Fahrenheit

Rate of Change Alarm:Yes

Configurable Software Filter:Yes

Configurable Channel Alarm and Fault Interrupts:Yes

Terminal Block Insertion or Removal Detection:Yes

    The A-B 1394C-SJT22-A Universal Analog Input Module is an advanced solution designed for industrial control systems requiring high accuracy and reliability. It is equipped with a robust design capable of handling various input types, including thermocouples, strain gauges, RTDs, voltage, and current signals.

    This module supports full software configuration without the need for setting module jumpers, making installation and setup straightforward. With six hardware analog-to-digital filtering frequencies, it allows independent channel selection for each input channel, ensuring high precision measurements.

    Safety features include RTD short circuit detection, user-defined scaling, and high, high-high, low, low-low alarm detection and reporting, providing comprehensive protection and monitoring capabilities.

    Installation is simple and efficient with the provided terminal block insertion/removal detection feature, ensuring easy maintenance and troubleshooting. The temperature display can be set to show either Celsius or Fahrenheit, offering flexibility based on the user’s preference.

    Designed with future expansion in mind, this module supports flash memory for firmware upgrades, ensuring that your system remains up-to-date and compatible with evolving standards and protocols.
